EBS-B2K5-B
Integ E Series The Power Extender

EBS-S5K1/7K5/10K/12K/15K/17K/20K/23K/25K-B

High Voltage
Residential
Stackable

Features

Sleek Design

Hidden handle with a clean, modern look that blends into any space.

Easy Installation

Snap-fit stacking with only two screws per pack for quick setup.

User-Friendly Operation

Remote upgrade and all-in-one power and alarm functions.

High Power Performance

Continuous charge/discharge up to 50A, expandable to 3 clusters in parallel.

Enhanced Security

Precise alarms, multi-level protection, and SN verification for safe operation.

Reliable System Integration

Upgraded BMS with visible energy tracking through IntegHub platform.

Power designed around
your life.

1

Enjoy peace of mind with reliable backup power that keeps your home running through outages.

2

Easily expand storage as your family’s energy needs grow, from daily use to EV charging.

3

Save more with smarter energy use, lowering bills while maximizing solar self-consumption.

Explore the design that
powers innovation

Indicator & Button

Connection Terminals

Technical specifications

Storage System	EBS-S5K1-B	EBS-S7K5-B	EBS-S10K-B	EBS-S12K-B	EBS-S15K-B	EBS-S17K-B	EBS-S20K-B	EBS-S23K-B	EBS-S25K-B
Module Number	2	3	4	5	6	7	8	9	10
Nominal Energy [kWh]	5.12	7.68	10.24	12.80	15.36	17.92	20.48	23.04	25.60
Nominal Voltage [V]	102.4	153.6	204.8	256.0	307.2	358.4	409.6	460.8	512.0
Voltage Range [V]	89.6-116.8	134.4-175.2	179.2-233.6	224.0-292.0	268.8-350.4	313.6-408.8	358.4-467.2	403.2-525.6	448.0-584.0
Max. Charge/Discharge Current [A]	50/50
Weight [KG]	90	122	154	186	218	250	282	314	346
Dimensions [W×D×H mm]	650x350x487	650x350x621	650x350x755	650x350x889	650x350x1023	650x350x1157	650x350x1291	650x350x1425	650x350x1559
Protection Degree	IP54

For more information, please download the
datasheet or product manual.
