INTEG M
3-8KW Hybrid Inverter
Single Phase|High Voltage
90 %
Max. Efficiency​
5 A
PV Input Current
20 ms
UPS Switch
5 A
Charge/Discharge
Talented
  • 97.6% max. efficiency
  • Max. 15A PV input current
  • Within 10ms UPS-level switching
  • Max. 30A charge/discharge current
  • IP65 protection degree
  • Integrated diecasting technology for body design
  • Advanced heat dissipation design
  • Great performance ensured by Solinteg MORE platform
Reliable
  • Convenient installation and O&M
  • Easy data check via both OLED display and App
  • Easy WIFI configuration via App
  • Low operating noise
Friendly
Hybrid Inverter
Product Overview

Type Designation

Battery Voltage Range

Max. Efficiency

No. of MPPTs

Charge & Discharge

UPS Switching Time

MHS-3K-30

85-465V

97.6%

1

30A

< 10ms

MHS-3.6K-30

85-465V

97.6%

1

30A

< 10ms

MHS-4.2K-30

85-465V

97.6%

2

30A

< 10ms

MHS-5K-30

85-465V

97.6%

2

30A

< 10ms

MHS-6K-30

85-465V

97.6%

2

30A

< 10ms

MHS-7K-30

85-465V

97.6%

2

30A

< 10ms

MHS-8K-30

85-465V

97.6%

2

30A

< 10ms
