INTEG M
4-12KW Hybrid Inverter
Three-Phase|High Voltage
5 A
Max. PV Input Current
5 %
Unbalanced Load
10 A
Max. Charge/Discharge
Integ-M-4-12KW
Talented
  • 98.2% max. efficiency
  • Smooth transition to backup power
  • 135-750V super wide battery voltage range
  • Max. 15A PV input current
  • Up to 110% unbalanced load
  • Up to 125% AC output overloading
  • Max. 120% back-up output overloading @60s
  • Parallel operation capacity with max.10 units
Powerful
  • IP65 protection degree
  • Integrated diecasting technology for body design
  • Advanced heat dissipation design
  • Great performance ensured by Solinteg MORE platform
Reliable
  • Convenient installation and O&M
  • Easy data check via both OLED display and App
  • Easy WIFI configuration via App
  • Low operating noise
Friendly
Hybrid Inverter
Product Overview

Type Designation

Battery Voltage Range

Max. Efficiency

No. of MPPTs

Charge & Discharge

MHT-4K-25

135-750V

98.1%

2

25A

MHT-5K-25

135-750V

98.1%

2

25A

MHT-6K-25

135-750V

98.1%

2

25A

MHT-8K-25

135-750V

98.2%

2

25A

MHT-10K-25

135-750V

98.2%

2

25A

MHT-12K-25

135-750V

98.2%

2

25A
